Plastik Supply Water PE HDPE PP PPR Pipe Tube Single Screw Extruder Produksi/Line Extrusion/Making Machine
Detail Produk
| Layanan purna jual: | Insinyur tersedia untuk melayani | Nomor Sekrup: | Satu |
|---|---|---|---|
| Kondisi: | Baru | Nilai Otomatis: | Sepenuhnya Otomatis |
| Aplikasi: | Pipa bergelombang | Nomor model: | SJ65/33 |
| Menyoroti |
mesin pipa expander,pipa pvc mesin socketing |
||
Deskripsi Produk
- Mesin makan
- Extruder kerucut satu sekrup
- Cetakan
- Tangki Kalibrasi Vakum
- Menarik mesin
- Mesin cetak
- Mesin pemotong pipa
- Kerangka pipa tumpukan
- Mesin bantu (memberi makan, menggelegar dan menghancurkan)
- Dilengkapi dengan pengontrol suhu impor dan inverter/konverter
- Kotak pengurangan gir bertulang keras dengan gigi karburasi dan dihancurkan
- Sistem pendingin paksa untuk kinerja tinggi, kebisingan rendah, dan umur panjang
- Desain pemasangan bahan ganda (busi berlubang dan alur halus)
- Sekrup dan tong dari 38CrMoALA nitrida untuk ketahanan terhadap keausan dan korosi
- Tersedia dalam konfigurasi ekstruder tipe knalpot
| Jenis | Diameter pipa (mm) | Output PVC (kg/jam) | Output PE/PP (kg/jam) | Kecepatan MAX (m/menit) | Kekuatan total (KW) |
|---|---|---|---|---|---|
| WR-160 | 90-160 | 150-250 | 200 sampai 300 | 6.0 | 9.7 |
| WR-250 | 110-250 | 250 sampai 350 | 250 sampai 350 | 5.0 | 8.6 |
| WR-500 | 200 sampai 400 | 650-750 | 250 sampai 500 | 3.0 | 16.9 |
| WR-800 | 500-800 | --- | 1000-1100 | 3.0 | 16.9 |
| WR-1200 | 800-1200 | --- | 1000-1200 | 1.0 | 30.0 |
| Model | LB110 | £ 250 | LB315 | £ 400 |
|---|---|---|---|---|
| Jangkauan pipa | 20-110mm | 75-250mm | 110-315mm | 180-400mm |
| Model sekrup | SJ65 | SJ75 | SJ75 | SJ75 |
| Kekuatan motor | 55KW | 90KW | 132KW | 160KW |
| Output | 150kg | 220kg | 400kg | 600kg |
Selama produksi mesin, kami memberikan update foto secara teratur tentang status peralatan. Setelah selesai, kami mengatur uji coba dan mengundang pembeli untuk memeriksa mesin di pabrik kami.
Kami menangani semua dokumentasi pengiriman dan logistik. insinyur kami menyediakan instalasi di tempat, komisi, dan pelatihan pekerja layanan.
Kami menawarkan garansi 18 bulan dari tanggal pengiriman dan dukungan teknis seumur hidup untuk panduan produksi.
Sorotan Produk
Jalur ekstrusi lengkap untuk pembuatan pipa plastik berkualitas tinggi dengan ketahanan suhu, ketahanan korosi, ketahanan abrasi, dan sifat kekuatan tinggi. Aplikasi Ideal untuk pipa pemintalan listrik, pipa pemintalan otomatis, sarung pelindung, alat mesin, kemasan dan mesin makanan, lokomotif ...
75-250mm PVC Pipe Electrical Conduit Water Supply Mesin Membuat
75-250mm PVC Pipe Electrical Conduit Water Supply Making Machine This complete PVC pipe production line manufactures high-quality PVC/UPVC pipes ranging from 16mm to 800mm in diameter. The system is engineered for producing electrical conduit pipes, water supply pipes, and construction plumbing pipes with various diameters and wall thickness specifications. Applications The manufactured UPVC pipes serve multiple applications including electrical conduit systems, water supply
Mesin Pembuat Pipa HDPE 50-250MM Garis Ekstrusi Pipa PE Otomatis Penuh Sekrup Tunggal
50-250MM HDPE Pipe Making Machine Extrusion Production Line Product Overview The HDPE pipes with large diameter are typically applied for fuel gas and water supply systems. These pipes feature excellent characteristics including heat resistance, aging resistance, high mechanical strength, environmental stress crack resistance, and good creep resistance. They serve as preferred conduits for ductwork systems and water supply networks between cities and suburbs. PE Pipe
Gas Air PE Pipe Extrusion Line Single Outlet 4 - 9m / Min Capacity
PE Pipe Extrusion Line HDPE gas water pipe machine, PE gas pipe extrusion line Specially-designed spiral moulds for PE pipes, with inside oil controlling temperature system. plastic machine Extruder adopts big L/D and multi mixing structure, which is more suitable for the PE low temperature extrusion production. PE PIPE PROCUTION LINE MAIN COMPONENTS: No Equipment Quantity 1 Vacuum loader and hopper dryer 1set 2 Single screw extruder 1set 3 Die-head 1set 4 color line
Dekorasi PVC Foam Board Extrusion Line 45 / 90mm Diameter Sekrup Ganda
PVC free foam sheet production line/foam board extrusion line / PVC foam decoration sheet production line Products characteristics 1) Water proof, anti-flaming, damp proof, rot proof, mothproof, light weight, keep temperature, sound and heat insulation and shock proof etc. 2) Color-way is not changed long time and not easy to aging under radiation resistance 3) This product can be manufactured by general wood processing tools; It can be drilled, sawed, nailed and dig.It is
