Garis Ekstrusi Pipa PVC Otomatis Penuh, Mesin Produksi Pipa 80KW 250KG
Detail Produk
| Nama Produk: | Jalur Ekstrusi Pipa PVC | Kemasan rincian: | pembungkus film |
|---|---|---|---|
| Kondisi: | baru | Aplikasi: | pembuatan pipa |
| Bahan baku: | PVC | Kelas Otomatis: | penuh Otomatis |
| Inverter: | ABB | Pengatur suhu: | omron |
| Sertifikat: | ISO CE | ||
| Menyoroti |
mesin pembuat tabung plastik,lini produksi pipa pvc |
||
Deskripsi Produk
Mesin Produksi Jalur Ekstrusi Pipa PVC Otomatis Penuh 80KW 250KG / H 18 * 2.5 * 3m
pipa pvc kerucut ekstruder sekrup kembar / peralatan ekstruder pipa plastik / mesin ekstrusi sekrup ganda
SJSZ seri ekstruder batang sekrup kembar kerucut terdiri dari sekrup barel, sistem transmisi roda gigi,
makan terukur, vakum deareating, pemanasan, pendinginan dan komponen kontrol listrik dll.
hal ini terutama digunakan dalam plasticizing, ekstrusi dan pembentukan pipa PVC, pelat, lembaran, film, profil, dan
granul, dll.
Peralatan utama
| Model | PVC16-63MM |
| SJSZ65/132 Pengekstrusi sekrup kembar berbentuk kerucut | 1 set |
| 16-63 cetakan pipa ganda PVC | 1 set |
| Tangki kalibrasi vakum (ganda) | 1 set |
| Mesin pengangkut (ganda) | 1 set |
| Mesin pemotong (ganda) | |
| Penumpuk | 1 set |
Parameter Standar
| 1 | Bahan | PVC |
| 2 | Kisaran diameter pipa: | 16-63mm |
| 3 | Kecepatan garis | Maks 12m/mnt (keluaran tunggal) |
| 4 | kapasitas maksimum | 250kg/jam |
| 5 | Total daya terpasang untuk seluruh saluran | 100KW |
| 6 | Konsumsi daya aktual | 80KW |
| 7 | Sistem manajemen | CE, ISO9001 |
| 8 | L*W*H | 18*2.5*3m |
Semua Parameter Teknis Conical Twin-Screw Extruder Seri SJSZ:
| Model | SJZ-51 | SJZ-55 | SJZ-65 | SJZ-80 | SJZ-92 |
| Diameter Sekrup (mm) | 51/105 | 55/110 | 65/132 | 80/156 | 92/188 |
| Maks.Kecepatan putar (rpm) | 40 | 38 | 38 | 37 | 36 |
| Motor Utama (kw) | 18.5 | 22 | 37 | 55 | 90 |
| Kapasitas (kg / jam) | 80~100 | 100~150 | 150~250 | 250~380 | 380~700 |
| Tinggi tengah (mm) | 1050 | 1050 | 1050 | 1050 | 1100 |
| Berat Bersih (kg) | 3000 | 3500 | 4000 | 5500 | 8000 |
| L*W*H | 3.6*1.1*2.1 | 3.6*1.1*1.2 | 4.2*1.5*2.4 | 4.7*1.5*2.4 | 6*1.6*2.5 |
