Single Screw PE Pipe Extrusion Line, Mesin Pembuat Pipa Pe Kapasitas Tinggi
Detail Produk
| Nama: | Jalur Ekstrusi Pipa PE | Aplikasi: | pembuatan pipa |
|---|---|---|---|
| Proses Plastik: | PE | Jaminan: | 12 bulan |
| Kisaran Diameter: | 20-630MM | Desain Sekrup: | Sekrup tunggal |
| Sertifikasi: | CE,ISO | voltase: | 380V 50HZ 3Phase (Disesuaikan) |
| Nilai Otomatis: | Penuh-Otomatis | Layanan Purna Jual Disediakan: | Insinyur tersedia untuk mesin layanan di luar negeri, dukungan online, dukungan teknis video, instal |
| Jaminan: | 1 Tahun | Warna: | Disesuaikan |
| Kontrol: | PLC+Layar Sentuh | ||
| Menyoroti |
jalur produksi pipa hdpe,mesin ekstrusi pipa plastik |
||
Deskripsi Produk
Mesin Ekstrusi Pipa PE Sekrup Tunggal, Mesin Pembuatan Pipa PE Kapasitas Tinggi
Parameter teknis utama:
| jenis | kisaran pipa ((mm) | Max. output ((kg/jam) | total daya ((kw) | L*W*H(m) |
| PE-250 | 110-250 | 350 | 230 | 44*2,5*3 |
| PE-400 | 160-400 | 600 | 400 | 45*3*3.5 |
| PE-630 | 315-630 | 800 | 490 | 56*3*3.5 |
| PE-800 | 500-800 | 1000 | 650 | 58 kali 3,5 kali 3.5 |
| PE-1000 | 630-1000 | 1200 | 760 | 62 kali 3,5 kali 3.5 |
| PE-1400 | 800-1400 | 1500 | 820 | 67*4*4 |
Daftar Mesin ekstrusi pipa air PE/HDPE:
| Tidak, tidak. | Peralatan |
| 1 | Pemasok dan Pengering Otomatis |
| 2 | SJ Extruder Sekrup Tunggal |
| 3 | SJ25×25 Co-Extruder |
| 4 | Cetakan (termasuk pemanas dan kalibrator) |
| 5 | Tangki vakum |
| 6 | Tangki pendingin air |
| 7 | Satuan pengalihan |
| 8 | Mesin pemotong otomatis |
| 9 | Mesin penggulung |
1- Mesin pembuatan pipa selang ini terutama digunakan untuk memproduksi pipa kebun, pipa pasokan air dan
drainase dalam konstruksi, kabel dll.
2- Pemilik pipa polietilen kepadatan menengah dan pipa polietilen kepadatan tinggi.
Yang pertama berlaku untuk transportasi gas buatan, gas alam, dan gas alam.
gas, gas minyak bumi cair, yang terutama digunakan untuk mengangkut gas alam.
