Garis Ekstrusi Pipa Multi PVC Profesional 37KW Daya Motor Tahan Aus Tinggi
Detail Produk
| DIAMETER PIPA: | 16-63MM | APLIKASI: | PIPA AIR |
|---|---|---|---|
| MODEL EXTRUDER: | SJSZ65/132 | TENAGA MOTOR: | 37KW |
| KAPASITAS: | 250KG/HR | PEMOTONG: | PEMOTONG SAW |
| KONTROL: | PLC | ||
| Menyoroti |
garis pipa plastik ekstrusi,lini produksi pipa pvc |
||
Deskripsi Produk
DIAMETER DUA STRAND DIAMETER 16-63MM TABUNG PVC JALUR MESIN PEMBUATAN
Fitur Teknis Utama
1. Hal ini terutama digunakan untuk memproduksi semua jenis pipa UPVC untuk pasokan air dan drainase pertanian, membangun pasokan air dan drainase dan peletakan kabel, dll.
2. Pemotong gergaji dan pemotong planet untuk pilihan
3. Mengubah beberapa bagian juga dapat menghasilkan pipa M-PVC, pipa C-PVC, pipa dinding spiral bagian dalam, pipa dinding berongga bagian dalam, pipa inti yang dibentuk.
4. Pengekstrusi sekrup kembar kerucut dan ekstruder sekrup kembar paralel untuk pilihan
5. Untai ganda dan untai empat untuk pilihan untuk pipa kecil
Aplikasi pipa pvc:
pipa pvc terutama digunakan dalam drainase pasokan air pertanian dan konstruksi. Pipa cpvc karena karakter khususnya, banyak digunakan dalam transportasi minyak dasar, pipa tahan suhu dan korosi bahan kimia, pipa drainase pasokan air panas dan pipa perlindungan listrik tegangan tinggi dan kabel listrik.
Spesifikasi
| Model: SJ45 Garis ekstrusi pipa biasa | ||||
| Barang | Satuan | Bagian | Nomor | Keterangan |
| 1 | Pengekstrusi SJ45 | sekrup & laras | 1 set |
45 mm, L/D=25:1, 38CrMoAIA, |
| kotak gigi | 1 set | pengerasan gigi, dipoles, horizontal | ||
| bingkai mesin | 1 set | Struktur baja | ||
| motor utama | 1 set | Frekuensi 11 kw bervariasi | ||
| panel kendali | 1 set | 5 zona kontrol suhu, 4 pendingin udara | ||
| 2 | Meja Ukuran Vakum | 1 set | panjang: 2,5 meter bahan permukaan: baja tahan karat Manual 3 dimensi yang dapat disesuaikan pompa vakum: 2.2 kw |
|
| 3 | Unit Menggambar | 1 set | 1,5 kw frekuensi bervariasi | |
| 4 | Unit Pemotongan | 1 set | 1,5 kw frekuensi bervariasi panjang efektif: 3 m rak pelepasan otomatis |
|
SPESIFIKASI:
| MODEL | DIAMETER PIPA (MM) | MODEL EXTRUDER | DAYA MOTOR (KW) |
| LB-32F | 16-32 (EMPAT PIPA) | SJSZ65/132 | 37 AC |
| LB-32E | 16-32 (PIPA GANDA) | SJSZ51/105 | 22 AC |
| LB-32W | 16-32 (PIPA GANDA) | SJSZ65/132 | 37 AC |
| LB-40E | 16-40 (PIPA GANDA) | SJSZ51/105 | 22 AC |
| LB-40W | 16-40 (PIPA GANDA) | SJSZ65/132 | 37 AC |
| LB-50E | 16-50 (PIPA GANDA) | SJSZ51/105 | 22 AC |
| LB-50W | 16-50 (PIPA GANDA) | SJSZ65/132 | 37 AC |
| LB-63W | 16-63 (PIPA GANDA) | SJSZ65/132 | 37 AC |
Sorotan Produk
DIAMETER DUA STRAND DIAMETER 16-63MM TABUNG PVC JALUR MESIN PEMBUATAN Fitur Teknis Utama 1. Hal ini terutama digunakan untuk memproduksi semua jenis pipa UPVC untuk pasokan air dan drainase pertanian, membangun pasokan air dan drainase dan peletakan kabel, dll. 2. Pemotong gergaji dan pemotong ...
